| Specifications | Camera Perfomance |
| Sensor | BAE CIS - 2020F SCMOS |
| Active Array Size | 2048 x 2048 pixels ( 4.2 Megapixel ) |
| Pixel Area | 6.5µm
x 6.5µm |
| Sensor
Area | 13.312 mm x 13.312 mm |
| 18.8mm diagonal |
| Peak QE% | >72% |
| Read Noise | 1.3e- ( RMS ) |
| 1.1e- ( Medium ) |
| Full - Well capacity | 30,000e- |
| Dynamic Range | 30,000 : 1 |
| Bit Depth | 16 - Bit |
| Readout
Mode | Rolling Shutter |
| Effective Gloval
Shutter |
| Binning | 2 x 2 ( on FPGA ) |
| | | | | | | | | | | | |
| | | | | | | | | | | | |
| Cooling Perfomance | Sensor Temperature | Dark Current |
| Air Cooled | -10°C @ 30°C Ambient | 0.06e- / pixel / second |
| Liquid Cooled | -25°C @ 30°C Ambient | 0.01e- / pixel / second |
| | | | | | | | | | | | |
| | | | | | | | | | | | |
| Specifications | Camera Interface |
| Digital Interface | PCI - Express |
| | | | | USB 3.0 | | | | | | | | |
| Lens Interface | C - Mount |
| Mounting Points | 2 x ¼ 20" mounting points
per side to prevent rotation |
| Liquid Cooling | Quick Disconnected Ports |
| | | | | | | | | | | | |
| | | | | | | | | | | | |
| Triggering Mode | Function |
| Input
Trigger Modes | Trigger - Firdt - Sequence triggeried on first
rising edge |
| Edge - Each frame
triggered on rising edge |
| SMART
Streaming : Fast interation through multiple exposure times | | | |
| Output
Trigger Modes | First Row : Exposure signal is high while first row
is acquiring data |
| Arry Rows : Expose
signal is high while arry row is acquring data |
| All Rows : Effective
Global Shutter - Exposure signal is high when all rows are acquiring data |
| Output Trigger
Signal | Exposure Out ( up to four signals ), Read Out,
Trigger Ready |
| | | | | | | | | | | | |
